Details
We engineered Áspero for pure, unapologetic speed, ready to take down finish lines, KOMs, PRs, and FKTs. A bike built without limits, for the riders looking to test them. It's stiff-Classics-racing stiff and performs like you'd want a road bike to perform off-road. We think that makes sense, and it's what we were trying to do when we were stuffing bigger tires into our existing frames and swapping in aftermarket forks to get a 40mm tire up front.
- Multiple Configurations
We designed Aspero with clearance for up to 700c x 40mm tires or 650b x 49mm tires. Of course, there are variables—rim width, tire casing, and tread depth—which will affect final clearance. We always recommend 4mm of clearance between the tire and frame.
**New Shimano road (not gravel) 12-speed front derailleurs reduce tire clearance in the rear of the frame to 700 x 38c or 650b x 45c.
- Two Position Adjustment
Trail—front-wheel response to rider input—is the most critical factor in high-velocity handling. Flipping the two-position "Trail Mixer" to compensate for the difference in circumference between a 650b and 700c tire maintains consistent handling by maintaining consistent trail figures.
- Balanced Handling
Stiffness and handling work together to ensure the bike tracks predictably and responds immediately to critical pedal and bracing inputs.
Frame Size | 48 | 51 | 54 | 56 | 58 | 61 |
---|---|---|---|---|---|---|
Reach | mm | 370 | 379 | 388 | 397 | 406 | 415 |
Stack | mm | 505 | 530 | 555 | 580 | 605 | 630 |
Head Tube Angle | 71° | 71.5° | 72° | 72° | 72° | 72° |
Front Center | mm | 583 | 592 | 602 | 619 | 637 | 654 |
Bottom Bracket Drop | mm | 78.5 | 78.5 | 76 | 76 | 73.5 | 73.5 |
Head Tube Length | mm | 83 | 107 | 133 | 159 | 188 | 214 |
Top Tube Length | mm | 512 | 532 | 553 | 575 | 591 | 608 |
Seat Tube Angle | 74.5° | 74° | 73.5° | 73° | 73° | 73° |
Standover Height | mm | 690 | 732 | 764 | 788 | 814 | 838 |
Trail | mm | 58.6(700C) / 58.1(650B) | 58.6(700C) / 58.1(650B) | 58.6(700C) / 58.1(650B) | 58.6(700C) / 58.1(650B) | 58.6(700C) / 58.1(650B) | 58.6(700C) / 58.1(650B) |
Wheel Size | 700C | 700C | 700C | 700C | 700C | 700C |
Fork Offset | mm | 52/57 | 49/54 | 46/51 | 46/51 | 46/51 | 46/51 |
Wheelbase | mm | 990 | 1000 | 1010 | 1027 | 1046 | 1063 |
Chainstay Length | mm | 420 | 420 | 420 | 420 | 420 | 420 |
Frame Size | Rider Height (cm) | Rider Height (in) |
---|---|---|
48 | 150 - 160 | 4'11" - 5'3" |
51 | 160 - 168 | 5'3" - 5'6" |
54 | 168 - 176 | 5'6" - 5'9" |
56 | 176 - 184 | 5'9" - 6'0" |
58 | 184 - 192 | 6'0" - 6'3" |
61 | 192 - 200 | 6'3" - 6'7" |
Specs
Fork | Cervélo All-Carbon, Tapered Áspero Fork with Adjustable Trail |
---|---|
Axles | Cervelo Indexed Thru-Axles w/ Lever, 12x100/142 |
Headset | FSA IS2 1-1/8 x 1-1/2 |
Seatpost | Cervélo SP19 27.2 Carbon |
Accessories & Extras |
Cervelo Rear Accessory Mount Smartpak 400A Top Tube Storage Bag |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Black / 48cm | 042677621058 | 0I0ASAFS1X48 | |
Black / 51cm | 042677621065 | 0I0ASAFS1X51 | |
Black / 54cm | 042677621072 | 0I0ASAFS1X54 | 210000014689 |
Black / 56cm | 042677621089 | 0I0ASAFS1X56 | |
Black / 58cm | 042677621096 | 0I0ASAFS1X58 | |
Black / 61cm | 042677621102 | 0I0ASAFS1X61 | |
Putty / 48cm | 042677621171 | 0I0ASAFS3X48 | |
Putty / 51cm | 042677621188 | 0I0ASAFS3X51 | |
Putty / 54cm | 042677621195 | 0I0ASAFS3X54 | |
Putty / 56cm | 042677621201 | 0I0ASAFS3X56 | |
Putty / 58cm | 042677621218 | 0I0ASAFS3X58 | |
Putty / 61cm | 042677621225 | 0I0ASAFS3X61 | |
Rose Champagne / 48cm | 042677621119 | 0I0ASAFS2X48 | |
Rose Champagne / 51cm | 042677621126 | 0I0ASAFS2X51 | |
Rose Champagne / 54cm | 042677621133 | 0I0ASAFS2X54 | |
Rose Champagne / 56cm | 042677621140 | 0I0ASAFS2X56 | |
Rose Champagne / 58cm | 042677621157 | 0I0ASAFS2X58 | |
Rose Champagne / 61cm | 042677621164 | 0I0ASAFS2X61 |
